2 Installation 21
3.6 Control I/O Connector
The control I/O port interfaces the LS-R700 to an external devices such as PLC.
• A twisted pair cable preferably with shield should be used and should be separated from the power line.
• The length should be as short as possible without slack.
• Twisting the common line with the signal lines will help reduce noise.
Phoenix Contact I/O Connector (Standard)
Strip off the insulation of the wire and insert it into the connector
terminal and tighten the screw on the side.
D-SUB Connector (Special Spec.)
Connect wires to the terminal with soldering.
Refer to
I
N
N
T
T
E
E
R
R
F
F
A
A
C
C
E
E
for the details.
Electric Shock
Be sure to turn off the main power before wiring.
Mishandling of the soldering iron could result in
burns or fire. Be sure to follow its instruction.
To Next Page
