Cosmo LS-R700 User Manual

3 Interface 39
3
Result Symbols in Leak Test Data Print Out and D Format
Result Symbol
Description
OK
Pass
CHG NG , CHG -NG
CHG Large Leak
BAL1 +NG
Insufficient Test Pressure detected by PS (TP LL)
UL NG , LL NG
Exceeding UL or LL in BAL2
UL NG , LL NG
Exceeding UL or LL in DET
UL2 NG , LL2 NG
Exceeding UL2 or LL2 in DET
PS 0!
Error 1: PS Offset Error
PS OV !
Error 2: PS Output Out of Range
TP <> !
Error 3: Test Pressure Error
B1TP<>!
Error 4: BAL1 Test Pressure Error
DPS 0!
Error 10: DPS Offset Error
AV ?!1
Error 11: Air Operated Valve Error 1
AV ?!2
Error 12: Air Operated Valve Error 2
AV ?!4
Error 14: Air Operated Valve Error 4
AV ?!5
Error 15: Air Operated Valve Error 5
AV ?!6
Error 16: Air Operated Valve Error 6
DPS ?!
Error 21: DPS stopped oscillating
V CLS!
Error 22: Stop Valves Closed
MCMP<>!
Error 23: Mastering Error
SRAM !
Error 51: Lo Battery SRAM Error
SLV0!
Error 52: SPI2_res AD Communication Error
SLV1!
Error 53: SPI1-res I/O Communication Error
E2PRM !
Error 59: Flash data area bad track Error
SDCD ?!
Error 60: Flash program area WR Error Kernel
SRAMc !
Error 61: SRAM checksum Error
