86 7 Operations Listed By Purposes
7
Test Data
Name of file:
YYYYMMDD_HH_CH#XX.csv
Year Month Date_Hour_Channel#.csv
ig: 20130723_00_CH#00.csv ( _ represents a space)
Pass:
Removable Disc\LS-R700\AUTO SAVE\LEAK DATA\ YYYYMMDD_HH_CH#XX.csv
Example:
Waveform Data
Name of file:
YYYYMMDD_HH_CH#XX.csv
Year Month Date_Hour_Channel#.csv
ig: 20130723_16_CH#00.csv ( _ represents a space)
Pass:
Removable Disc\LS-R700\AUTO SAVE\WAVE DATA\ YYYYMMDD_HH_CH#XX.csv
Example:
FILE NAM
LSR700\AUTO SAVE\WAVE DATA\CH#00\20130723 16 CH#00.csv
DATE ########
Sample#
Test Press
DPS Raw w
DPS Raw [
Leak Stage
1 -2.254 29.462 29.462 29.462 0 0
2 -2.269 29.465 29.465 29.465 DL1 1
3 -2.289 32.431 32.431 32.431 DL1 1
4 -2.272 35.703 35.703 35.703 PCHK 5
5 -2.243 24.966 24.966 24.966 PCHK 5
6 -2.218 21.396 21.396 21.396 CHG 6
Test Pressure
Unit is fixed to k[Pa]
Leak
Selected Unit
Stage
DL1: Charge Delay
CHG: Pressurization
BAL1: Equalization
BAL2: Stabilization
DET: Detection
BLW: Air-Blow
EXH: Exhaust
DPS Raw [Pa]
Unit is fixed to [Pa]
DPS Raw w/o A/Z [Pa]
Unit is fixed to [Pa]
Leak Unit
Pa
kPa
mL/s
L/min
Judgment
Pass
BAL UL
BAL LL
DET UL2
DET UL
DET LL
DET LL2
User Mode
Currently unused.
DPS Unit
Pa
kPa
Test Pressure Unit
kPa
MPa
Mode
Leak Test
Mastering
NR (Noise Reduction)
FILE NAME
LSR700\AUTO SAVE\LEAK DATA\CH#00\20130723 00 CH#00.csv
CH# BAL Leak DET Leak
Comp Valu
Mastering DPS Raw
Test Press
Judgment Mode
User Mode
Leak Unit
DPSRawUn
TPress Un
DET UL DET LL
0 0 0 0.7 0.7 0.8 0.8 OK Leak Test --- Pa Pa kPa 100 -100
0 0.2 1.8 0 0 1.8 1.8 OK Mastering --- Pa Pa kPa 100 -100
0 -2.3 1638.4 0 0 1638.4 1638.4
BAL2 L WS
Mastering --- Pa Pa kPa 100 -100
0 999.9 1598.1 0 0 1598.1 1598.1
BAL2 L WS
Leak Test --- Pa Pa kPa 100 -100
