Technical Specifications
90
Table 4-6-7 SM231 DIP switch configuration
Items
Switch
Setting
TC type
SW3
0 - J; 1 - K
Open-wire detect
direction
SW4
0 - Upscale (+3276.7 degrees); 1 - Downscale
(-3276.8 degrees)
Measurement Unit
SW5
0 - Celsius; 1 - Fahrenheit
Cold-junction enable
SW6
0 - Yes; 1 - No
Thermocouple measurement range
