Table 4-6-8 231-7HF32 current PID module specifications
Features
Dimension(W x H x D)
120.5 x 80 x 62 mm
Weight
210 g
Insert I / O terminal
No
Power consumption
Bus(5 V DC)
87 mA
L+
37 mA
Power
1.8 W
Input features
Type
8, analog
Input range/resistance
Current input
Maximum Permitted
input voltage
30 V DC
Isolation
Field-logic
500 V AC
Logic- 24 VDC
500 V AC
24 VDC-logic
500 V AC
Update time
825 ms(all channels)
Measurement principle
SIGMA-DELTA
Resolution
15 bit + signal
Temperature
0.1 ℃ / 0.1 ℉
Noise suppression
85 dB
Noise frequency
50 / 60 / 400 Hz
CMV
120 V AC
CMR
120 dB @120 V AC
Basic error
0.1% FS(current)
Repeatability
0.05% FS
Diagnosis program
LED: EXTF, SF
Maximum cable length
100 m —sensor
Max cable resistance
10
PID features
PID algorithm
PID+FUZZY parameter self-adjusted
Sampling time
1s
Minimum output pulse
width
10ms
PID type
P, PI, PD, PID
PID output type
Analog or PWM
PID output polarity
Unipolar or bipolar
SM231 current PID module(CTH2 231-7HF32)
