COTRUST CTH200 Series User Manual

CTH200 Series PLC User Manual
101
General
Order No.
CTH2 277-0AC32
Dimension (W×H×D)
71.3 × 96 × 62 mm
Digital input
Ports
2 RJ45 port for CANopen
Rated input voltage
24VDC
Type
Source/Drain (IEC class 1 source point)
Max continuous voltage
30VDC
Voltage surge
35VDC for 0.5s
Input delay
6.4ms (min. 6.3ms)
Isolation (Field to Logic)
Yes
Output on simultaneously
8 (all at 55℃)
Cable length
Shield
Max 500m
Unshielded
Max 300m
Digital Output
Type
Solid-MOSFET (Source)
Rated output voltage
24VDC
output voltage range
20.4~28.8VDC
Output current (max at logic
1)
0.5A
Output groups
1
Outputs per common
6
Output on simultaneously
6
Maximum current for single
group
4.5A
Surge current
8A for 100ms
Isolation
Optical couple isolation, 500VAC for 1 minute
Output delay
OFF-ON
Max 15μs
ON-OFF
Max 130μs
Cable length
Shield
Max 500m
Unshielded
Max 300m
Wiring diagram
SM277C CANopen slave module (CTH2 277-0AC32)

COTRUST CTH200 Series Specifications

General

Brand	COTRUST
Model	CTH200 Series
Category	Controller
Language	English
