CTH200 Series PLC User Manual
113
Filter
Combined hardware filter with software one
Power supply
With 5V DC power supply for modules
Input features
Type
Single-ended input(Unipolar/bipolar)
Counts
2
Full-scale voltage
0 ~ +12V
Max input voltage
+30V DC
Input resistance
≥100K
Data format
0 ~ +32000
Input step
response
Max. 200ms
DAC time
50ms
Isolation
No
Resolution
12 bits
Noise suppression
Typical: -20dB@50HZ
Accuracy
Worst
±2% full-range(0℃-55℃)
Typical
±1% full-range(25℃)
Repeatability
±0.05% full-range
Output features
Type
Unipolar/bipolar
Counts
2
Voltage output
+ 12V ± 5%
PWM output
±12V ± 5%
PWM parameter
PWM range data
format
0 ~ 1000
Full-range
0(-12V); 1000(+12V)
Output duty cycle
tolerance
±0.5% full-range
Frequency range
1000Hz ± 3%
Voltage output time
< 3us
Rise time Tr
< 2us
Fall time Tf
< 2us
Max output drive
≥1000Ω
+12V enable output
current
12mA(RL=0Ω)
6mA(RL=1KΩ)
4mA(RL=2KΩ)
Terminal definition
