COTRUST CTH200 Series User Manual

Appendix
190
• PID parameter input(CPU to modules)
Items
Address
Value set range
Actual value
Setting
temperature
VW A+128
0~13000
0~1300
Control byte
When VB A+130 bit = 0
V( A+130).0
PID stop, no output
PID run
V( A+130).1
Integral always work, Kp
do not self-tuning
Integral separate Kp
self-tuning
V( A+130).2
PID unipolar output,
0~32000
PID bipolar output,
-32000~32000, both heat
and cool
V( A+130).3
Unused
V( A+130).4
Integral works
V( A+130).5
Differential works
V( A+130).6
Actual temperature filter,
stronger ant jamming
capability
Actual temperature do not
filter
PID pulse
output cycle
setting
VW A+132
1~255
Kp
VW A+134
0~9999
0~999.9
Ti
VW A+136
0~3600
Td
VW A+138
0~3600
• Heating pulse output address
Channel 0 pulse output
V X.0
Channel 1 pulse output
V X.1
Channel 2 pulse output
V X.2
Channel 3 pulse output
V X.3
Channel 4 pulse output
V X.4
Channel 5 pulse output
V X.5
Channel 6 pulse output
V X.6
Channel 7 pulse output
V X.7
• Cooling pulse output address
Channel 0 pulse output
V Y.0
Channel 1 pulse output
V Y.1
Channel 2 pulse output
V Y.2
Channel 3 pulse output
V Y.3
Channel 4 pulse output
V Y.4
Channel 5 pulse output
V Y.5
Channel 6 pulse output
V Y.6
Channel 7 pulse output
V Y.7
