COTRUST CTH200 Series User Manual

CTH200 Series PLC User Manual
249
EN
SecCalbrate
TarePreset
Channel
SecCalWeight
MinWeight
Step
StandstillTime
StandstillRange
TareInput
Status
SecCalValue
Weight_Extend
② Function: Realize second calibration, set minimum weight, digital phase step, pause status
detection and preset tare.
③ Parameter
Name
Description
I/O
Type
Value
range
Note
SecCalibrate
Second calibration,
effective in rising
edge
IN
BOOL
--
--
TarePreset
Preset tare
IN
BOOL
--
--
Channel
Channel number
IN
BYTE
--
0-6
SecCalWeight
Weight of second
calibration
IN/OUT
INT
0
0 indicates no second
calibration
MinWeight
Minimum weight
IN/OUT
INT
20
This weight value can
only use for calibration
records with specified
digital steps above the
minimum weight. The
minimum weight
depends on the type
of sensor.
Step
Digital phase step
IN/OUT
BYTE
1
Range is 1, 2, 5, 10,
20, no other definition
StandstillTime
Pause time
IN/OUT
INT
1000
Unit: ms
StandstillRange
Pause range
IN/OUT
INT
10
TareInput
Tare input
IN/OUT
INT
0
Preset tare
SecCalValue
Second calibration
analog value
IN/OUT
WOR
D
0
Status
Status byte
OUT
BYTE
--
Status note:
Bit
Name
Note
Bit0
Weight of second
calibration is too small
The weighing difference between second and first
calibration cannot be more than 5%FS
Bit1
Digital phase step error
Digital phase step can only be 1, 2, 5, 10, 20
Bit2
Pause time error
Pause time must>0
