Appendix
328
SMD38
HSC0 new initial value, set SM37.6 as 1 after write new value into
SMD38, then the current value will be updated
SMD42
HSC0 new preset value, set SM37.5 as 1 after write new value into
SMD42, then the current value will be updated
HSC1
SMB46
HSC1 counter status
SM46.0~SM46.4
Reserved
SM46.5
HSC1 current count direction bit: 1=addition count
SM46.6
HSC1 current value equal to preset value bit: 1=equal
SM46.7
HSC1 current value more than preset value bit: 1=more than
SMB47
HSC1 control byte
SM47.0
Reset valid control bit: 0= high level reset valid, 1=low level reset
valid
SM47.1
HSC1 start valid level control bit: 0= high level, 1=low level
SM47.2
Count speed selection of orthography counter: 0=4x count speed;
1=1x count speed
SM47.3
HSC1 direction control bit: 1= addition count
SM47.4
HSC1 update direction: 1= update direction
SM47.5
HSC1 update preset value: 1=write new preset value to HSC0
SM47.6
HSC1 update current value: 1=write new initial value to HSC0
SM47.7
HSC1 valid bit: 1=valid
SMD48
HSC1 new initial value, set SM47.6 as 1 after write new value into
SMD48, then the current value will be updated
SMD52
HSC1 new preset value, set SM47.5 as 1 after write new value into
SMD52, then the current value will be updated
HSC2
SMB56
HSC2 counter status
SM56.0~SM56.4
Reserved
SM56.5
HSC2 current count direction bit: 1=addition count
SM56.6
HSC2 current value equal to preset value bit: 1=equal
SM56.7
HSC2 current value more than preset value bit: 1=more than
SMB57
HSC2 control byte
SM57.0
Reset valid control bit: 0= high level reset valid, 1=low level reset
valid
SM57.1
HSC1 start valid level control bit: 0= high level, 1=low level
SM57.2
Count speed selection of orthography counter: 0=4x count speed;
1=1x count speed
SM57.3
HSC2 direction control bit: 1= addition count
SM57.4
HSC2 update direction: 1= update direction
SM57.5
HSC2 update preset value: 1=write new preset value to HSC0
SM57.6
HSC2 update current value: 1=write new initial value to HSC0
SM57.7
HSC2 valid bit: 1=valid
SMD58
HSC2 new initial value, set SM57.6 as 1 after write new value into
SMD58, then the current value will be updated
SMD62
HSC2 new preset value, set SM57.5 as 1 after write new value into
SMD62, then the current value will be updated
