COTRUST CTH200 Series User Manual

CTH200 Series PLC User Manual
29
Transmission speed
10Mbps/100Mbps self-adaption
Self-adaption
cross-connect
Yes
No
Industrial Ethernet
interface
(10/100Mbps)
RJ45
Protocol type
UDP_PPI, MODBUS_TCP, Ethernet
Configuration method
PC Searching PLC and downloading configuration via Ethernet
port
Connections (Max.)
Up to 8 UDP and 6 TCP connections for each PLC
IT connection (Max.)
8 UDP_PPI
connections
5 MODBUS_TCP
connections,
irrespective of
master/slave
8 UDP_PPI connections, 4 masters/4
slaves.
4 MODBUS_TCP connections, 2 masters/2
slaves
User data volume
Up to 200 bytes used for TCP/IP
Up to 240 bytes used for MODBUS_TCP
COM
Local: 1~65535
Remote MiCO server: mico.co-trust.com
Port: 20000
Time for start or restart
after reset
Approx. 5s
Indicators
SF (RED): ON - system error, OFF - normal
RUN (Green): ON - Run, OFF - Stop
STOP (Orange): ON - Stop, OFF - Run
RMC (Green): ON - Enable RMC, OFF - Disable RMC
LINK/ACT (Green): ON - connected, flash - transfer, OFF -
disconnected
Cable length (Max.)
100m
Isolation
COM port is isolated
Cable
Ethernet: CAT5e shield cable
Table 4-2-4 Digital input specifications of CTH200 PLC
Item
H224/H224X
H226L/H226XL
H228XL
Input
Counts
14
24
36
Type
Drain/Source
Rated Voltage
24VDC
Voltage Range
20.4~28.8VDC
Surge
35VDC for 0.5s
Logic 1 (min.)
15 VDC, 2.5mA
Logic 0 (max.)
5 VDC, 1mA
Permissible leakage
current (max.)
1mA
