COTRUST CTH200 Series User Manual

Technical Specifications
30
Input filter
Configurable, H224/H226L support 3.4ms and 6.4ms;
H224X/H226XL/H228XL support 0.2ms, 0.4ms, 0.8ms, 1.6ms,
3.2ms, 6.4ms, 12.8ms, default as 6.4ms
Isolation (field to logic)
Isolation groups
500VAC for 1 minute
Refer to wiring diagrams
Inputs on
simultaneously
All
Max Cable
length
Unshielded
300 m for normal inputs
Shielded
500 m for normal inputs, 50 m for HSC inputs
Table 4-2-5 Digital output specifications of CTH200 CPUs
Items
Transistor
Relay
H224/H226L
H224X/H226XL
H224/H226L
H224X/H226XL
H228XL
Type
Solid State-MOSFET
(Sourcing)
Dry contact
Rated voltage
24VDC
24VDC or 110V/220VAC
Voltage Range
20.4~28.8VDC
5~30VDC: 5~250VAC
Max Surge current
8A for 100ms
5A for 4s@10% duty cycle
Max Rated current per
point
0.5A
2.0A
Max Rated current per
common
6A
8A
Max Lamp load
5W
DC 30W, AC 200W
On State resistance
(contact)
0.3 Ω typical (0.6 Ω max.)
0.2 Ω (maximum when new)
Isolation Optical
(galvanic, field to logic)
500VAC for 1 minute
1500VAC for 1 minute
Delay
(max.)
Off to on
H224/H226L(transistor): max 15μs
H224/H226L(relay): max 50μs
H224X/H226XL(transistor): 2μs(Q0.0, Q0.1), max 15μs (all other)
H224X/H226XL/H228XL(relay): max 10ms
On to off
H224/H226L(transistor): max 130μs
H224/H226L(relay): max 200μs
H224X/H226XL(transistor): 10μs(Q0.0, Q0.1), max 130μs (others)
H224X/H226XL/H228XL(relay): max 10ms
Lifetime mechanical
cycles
--
10,000,000 (no-load)
Lifetime contacts
100,000 (rated load 2A)
Outputs on
simultaneously
All
Connecting two outputs
in parallel
No
Yes, only outputs in same group
Max Cable
length
Shielded
500m
150m
Unshielded
