COTRUST CTH200 Series User Manual

Technical Specifications
32
Bit address range
V0.0~V8191.7
V0.0~V8191.7
V0.0~V10239.7
Byte address
range
VB0~VB8191
VB0~VB8191
VB0~VB10239
Word address
range
VW0~VW8190
VW0~VW8190
VW0~VW10238
DWord address
range
VD0~VD8188
VD0~VD8188
VD0~VD10236
Access
Immediate /direct/indirect access
Data hold
Power-down data retention is not supported
Special memory (SM)
H224/H226L
H224X/H226XL/H228XL
Storage
550bytes
650bytes
Bit address range
SM0.0~SM549.7
SM0.0~SM649.7
Byte address
range
SMB0~SMB549
SMB0~SMB649
Word address
range
SMW0~SMW548
SMW0~SMW648
DWord address
range
SMD0~SMD546
SMD0~SMD646
Access
The first 30 bytes can be accessed with read-only, support direct/indirect
access
Note:
For detailed information about SM, refer to appendix L Instruction Set.
Internal memory (M)
Storage (bytes)
32 bytes
Bit address range
M0.0~M31.7
Byte address
range
MB0~MB31
Word address
range
MW0~MW30
DWord address
range
MD0~MD28
Access
Direct /indirect access
Data hold
Configurable as all or partial retention at power-down
Local variable (L)
Storage (bytes)
64 bytes
Bit address range
L0.0~L63.7
Byte address
range
LB0~LB63
Word address
range
LW0~LW62
DWord address
range
LD0~LD60
Access
Direct access
Data hold
Retention for subprogram (only for H224X and H226XL), no data
retention.
Accumulator register (AC)
Counts
4
Bit address range
Not support
Byte address
range
AC0~AC3
Word address
range
AC0~AC3
