CTH200 Series PLC User Manual
33
DWord address
range
AC0~AC3
Access
Direct access
Data hold
Not support
Sequence Control Relay (S)
Storage (bytes)
32
Bit address range
S0.0~S31.7
Byte address
range
SB0~SB31
Word address
range
SW0~SW30
DWord address
range
SD0~SD28
Access
Direct /indirect access
Data hold
Not support
Timer (T)
-
H224/H226L
Type
Resolution
Quantity
Number
Max. time
TONR
1ms
2
T0, T64
32.767s
10ms
8
T1~T4, T65~T68
327.67s
100ms
54
T5~T31, T69~T95
3276.7s
TON/TOF
1ms
2
T32, T96
32.767s
10ms
8
T33~T36, T97~T100
327.67s
100ms
182
T37~T63, T101~T255
3276.7s
Timer (T)
-
H224X/H226XL/H228XL
Type
Resolution
Quantity
Number
Max. time
TONR
1ms
2
T0, T64
32.767s
10ms
8
T1~T4, T65~T68
327.67s
100ms
54
T5~T31, T69~T95
3276.7s
TON/TOF
1ms
2
T32, T96
32.767s
10ms
8+256
T33~T36, T97~T100,
T256~T511
327.67s
100ms
182
T37~T63, T101~T255
3276.7s
Access
Counter register support both direct and indirect access, only direct
access for status bit
Retention
Configurable for the current count value, not for status bit
Counter (C)
No.
256
Counting mode
Upward/downward/both upward and downward
Max count value
32767
Access
Support direct/indirect accessing for counter register, only direct
accessing for status bit
Retention
Configurable for the current count value, not for status bit
Table 4-2-8 Data types of CTH200 PLC
Type
Size
Description
Value range
BOOL
1bit
BOOL value
0~1
Byte
8bits
Unsigned byte
0~255
