COTRUST CTH200 Series User Manual

Technical Specifications
46
Optical (galvanic,
field to logic)
500VAC, last within 1 minute
Isolation groups
8 points
Output delay(RL = 50Ω)
Off－on
Maximum 50μs
On－off
Maximum 200μs
Maximum Cable length
Unshielded
150m
Shielded
500m
Wiring diagram
SM222 transistor output modules (CTH2 222-1BF32)
SM222 transistor output modules (CTH2 222-1BH32)
SM222 transistor output modules (CTH2 222-1BL32)
CTH2 222-1BL接线图
SM 222 DC
CTH2 222- 1B L32
0 1 2 3 4 5 6 7
0 1 2 3 4 5 6 7
0 1 2 3 4 5 6 7
0 1 2 3 4 5 6 7
1M 2M 2L+
3M
3L+
1L+
4L+4M
