Relay output
Table 4-3-4 Digital output modules specifications
Features
8 outputs, relay
16 outputs, relay
Order No.
CTH2 222-1HF32
CTH2 222-1HH32
Dimension(W×H×D)
46 × 96 × 62mm
71.3 × 96 × 62mm
Power supply consumption
Power
2W
3W
+5VDC current
68mA
115mA
Output features
Counts
8
16
Type
Relay－dry contact
Rated output voltage
DC: 5~30V, AC: 5~250V
Output current
Signal "1"
2A
Output groups
2
4
Output counts for each
group
4
Output on simultaneously
8
16
Maximum current each
group
8A
Lamp load (max.)
5W
On state resistance
(contact)
0.2Ω
Leakage current (max.)
7A, with contact closing
Surge current (max.)
Additional provide
Isolation
Counts
4
Coil and logic current
No
Coil and contact
1500VAC, last 1 minute
Resistance (Coil and
contact)
Minimum 100MΩ
Relay features
On/off delay
15ms
On/off frequency(max)
1Hz
On/off time(no-load)
30,000,000
Contact life(rated load)
300,000
Maximum Cable length
Unshielded
150m
Shielded
500m
Wiring diagram
SM222 relay output module(CTH2 222-1HF32)
