COTRUST CTH200 Series User Manual

CTH200 Series PLC User Manual
49
field to logic)
Isolation Groups
4 points
8 points
Input delay (max.)
4.5ms
Leakage current
(max.)
1mA AC
Output on simultaneously
40℃
4
8
16
50℃
4
8
16
Output
Counts
4
8
16
Type
Solid MOSFET
Output Voltage
Rated load Voltage
24VDC
Range
20.4~28.8VDC
Logic "1"
Min. 20VDC
Logic "0"
Max. 0.1VDC (at 10KΩ load)
Output Current
Rated current per
point (max.)
0.5A
Outputs per
common
4
8
Output on
simultaneously
4
8
16
Rated current per
common (max.)
2A
4A
Lamp load (max.)
5W
On state resistance
(contact)
0.3Ω
Leakage current
(max.)
10mA
Surge current (max.)
8A, 100ms
Isolation
Optical (galvanic, field to logic), 500VAC for 1 minute
Isolation groups
4
4/4/8
Output Delay (RL = 50Ω)
Off to On
Max 50ms
On to Off
Max 200ms
Cable length (max.)
Unshielded
150m
Shielded
500m
Caution
24VDC digital expansion modules support short, overcurrent and overvoltage
protection.
