COTRUST CTH200 Series User Manual

Technical Specifications
50
Wiring diagram
SM223 digital I/O module(CTH2 223-1BF32)
SM223 digital I/O module (CTH2 223-1BH32)
1M
SM 223 DC/DC
CTH2 223- 1B H32
1M 2M
0 1 2 3 4 5 6 7
4 5 6 70 1 2 3
1L+
CTH2 223-1BH接线图
SM223 digital I/O module (CTH2 223-1BL32)
Relay Output
Table 4-3-6 Digital I/O modules Specifications
Features
4DI×24VDC
4DO×Relay
8DI×24VDC
8DO×Relay
16DI×24VDC
16DO×Relay
Order No.
CTH2 223-1HF32
CTH2 223-1PH32
CTH2 223-1PL32
Dimension
Size(W×H×D)
46 × 96 × 62mm
71.3 × 96 × 62mm
138 × 96 × 62mm
Power Supply
Power Loss
2W
3W
6W

COTRUST CTH200 Series Specifications

General

Brand	COTRUST
Model	CTH200 Series
Category	Controller
Language	English
