USB Port
Operator's Manual 3-5
3.11
USB Port
The USB port allows data from the INVOS™ system to be transferred via a USB 2.0 flash memory
drive to other devices, such as a PC or other devices that have a USB port. A USB 2.0 flash memory
drive is supplied at the time of purchase. The USB flash drive allows the operator to download
INVOS™ system data in real-time (every 5–6 seconds) and stored (every 30 seconds) case history.
The USB port also allows for software upgrades (see section 7.3 Using the USB Port).
 Note:
USB flash drives not supplied by Covidien may not meet system requirements. Additional drives may be
ordered from Covidien (see section 3.12 Accessories).
3.12 Accessories
 WARNING:
Accessories not supplied by Covidien may not meet IEC 60601-1 standards. Contact the Covidien
Customer Service Department for compatible products that meet these requirements.
REF number Description
RSC-1 Reusable sensor cable channel 1 (blue), INVOS™ 5100C
RSC-2 Reusable sensor cable channel 2 (taupe), INVOS™ 5100C
RSC-3 Reusable sensor cable channel 3 (orange), INVOS™ 5100C
RSC-4 Reusable sensor cable channel 4 (green), INVOS™ 5100C
SAFB-SM INVOS™ adult regional saturation sensor (>40 kg)
PMAC71RSC-L-CH1
Reusable sensor cable for 5100C, channel 1
1
PMAC71RSC-L-CH2
Reusable sensor cable for 5100C, channel 2
1
PMAC71RSC-L-CH3
Reusable sensor cable for 5100C, channel 3
1
PMAC71RSC-L-CH4
Reusable sensor cable for 5100C, channel 4
1
SPFB INVOS™ pediatric regional saturation sensor (<40 kg)
CNN Disposable OxyAlert NIRSensor, neonatal—cerebral (<5 kg) with sensor cable
SNN Disposable OxyAlert NIRSensor, neonatal—somatic (<5 kg) with sensor cable
CNN/SNN Disposable OxyAlert NIRSensor, neonatal—cerebral/somatic (<5 kg) with sensor cable
PMSENS71-A
Adult rSO
2
sensor
2
5100C-PA Preamplifier A with cable, channel 1 and 2, INVOS™ 5100C
