Run Function (Patient Monitoring) in Normal Mode
Operator's Manual 6-5
Select <–, –>, and NEXT ROW to scroll through the characters and SELECT to enter highlighted
character. When entry is complete, select DONE in the Patient identifier entry screen to save the
unique alphanumeric identification and display the Main screen.
Up to 24 alphanumeric characters may be entered.
Entering or Editing Patient Identifier in Run Function
To enter or edit a patient identifier, press the HOME key to display the Main screen, then
perform the following navigation bar options:
Select <–, –>, and NEXT ROW to scroll through the characters and SELECT to enter highlighted
character. When entry is complete, select DONE in the Patient identifier entry screen to save the
unique alphanumeric identification and display the Main screen.
Up to 24 alphanumeric characters may be entered.
6.5 Run Function (Patient Monitoring) in Normal Mode
The Run function is for real-time rSO
2
trend monitoring.
Once INVOS™ system components are connected and the system is on, select NEW PATIENT or
PREVIOUS PATIENT. The monitor displays the Patient identifier screen followed by the Main
screen and Run function (rSO
2
trending) begins (see sections 3.4 Installation, 3.15 Adult and Pedi-
atric Regional Saturation Sensor Application, and 3.16 Infant/Neonatal OxyAlert NIRSensor Sensor
Application).
Note:
The informational message “RESTORING PREVIOUS PATIENT DATA” appears when selecting PREVIOUS
PATIENT and there is a large volume of data to recall.
In Run function, the operator can set baseline status, mark an event, and adjust User configuration
menu settings (see sections 6.5.3 Alarm Limits, 6.5.4 Alarm Volume, 6.5.5 rSO2 Scale, 6.5.6 Time Scale
in User Configuration Menu, 6.5.7 USB Storage Rate, 6.5.8 Event Mark List, 6.5.9 Data Channel Labels,
6.5.10 Color-Coded Data Channel Labels, 6.5.11 Two- or Four-Channel Monitoring, and 6.5.12 Restore
Defaults).
BASELINE MENU EVENT MARK ALARM AUDIO ON/OFF NEXT MENU
OUTPUT SELECT USER CONFIGURATION TIME SCALE NEXT MENU
REVIEW PATIENT ID PREVIOUS MENU MAIN MENU
<– –> NEXT ROW SELECT
<– –> NEXT ROW SELECT
