Covidien INVOS 5100C - Table 6-5. Status Messages-Rso2 Value Displayed

Operation
6-30 Operator's Manual
Status Codes
Status codes are numbers associated with specific conditions that are displayed in the Tabular
trends screen as lines of data in Run function and Case archive function (see section 5.1.10 Tabular
Trends Screen, Table5-1., Table6-5.and Table6-6.). The status codes help the user to identify
alarm and status message conditions and troubleshoot the system setup.
Alarms and Status Messages with rSO
2
Values Displayed
During normal monitoring situations when rSO
2
values are being displayed, alarm and status
messages may appear at the top of the Main screen. Actions in Table6-5. are listed to assist the
operator to try to correct a problem, if necessary. Additional operating indications to assist the
user will appear on the screen at the right of the corresponding affected channel label indicator
(for example, two-digit rSO
2
values turn yellow when below baseline desaturation threshold).
Table6-5.Status Messages—rSO
2
Value Displayed
Status message Status code Color, location Cause Action
ALARM HIGH accompa-
nied by alarm tone
5 Red, top right; corre-
sponding rSO
2
value is
red
Upper alarm limit is
exceeded.
Profile patient.
ALARM LOW accompa-
nied by alarm tone
6 Red, top right; corre-
sponding rSO
2
value is
red
Lower alarm limit is
exceeded.
Profile patient.
BATTERY LOW accompa-
nied by alarm tone
9 Yellow, top right Battery power is critical. Plug in A/C power and
turn master (mains)
switch on.
COM PORT UNAVAIL-
ABLE
12 Yellow, top right Output device not con-
nected.
Check connections with
Com port device (PC).
PRINTER UNAVAILABLE 13 Yellow, top right Printer not connected. Check connections with
Com port device (PC),
power connection, and
online status.
USB FULL 20 Yellow, top right USB flash drive memory
is full.
Insert a blank flash drive.
USB STORAGE ERROR 14 Yellow, top right USB flash drive error. Check USB flash drive
connection. Insert a
flash drive.
DATE AND TIME N/A Green, top left N/A N/A
ADULT, PEDIATRIC OR
NEONATAL
N/A Green, top center Adult, pediatric, or
infant/neonatal applica-
tion dependent on
sensor model used.
N/A
