Operation
6-8 Operator's Manual
To set an individual channel baseline, press the HOME key to display the Main screen, then
perform the following navigation bar options:
Select the channel or channels to set the baseline at the current rSO
2
value. This will display an
event mark line and code on the screen in the graph area for the individual channel only.
When finished, press the HOME key to exit the Baseline menu and return to the Main screen.
Manually Set to Previous rSO
2
Value Baselines
WARNING:
When using the manual set baseline feature, the baseline values will be reflected on the screen and
in the case history file. To capture the new baseline on the USB drive or digital output, the case
should be downloaded in case history, before turning off the monitor, immediately at the
completion of the case (see section Case History Data to USB Flash Drive for Downloading Case Data
at the End of a Case). If the case runs overnight and the manual set baseline is set to a time
corresponding to the previous day, the manual set baseline is not displayed in the case history of
the previous day.
The manually set baseline feature is used when previous rSO
2
values are to be set as baselines (for
example, an awake baseline was forgotten to be set prior to induction). The Manual baseline set
screen will appear as tabular rSO
2
data. To select and manually set previous rSO
2
values, press the
HOME key to display the Main screen, then perform the following navigation bar options:
Select NEXT PAGE, PREVIOUS PAGE, or LAST PAGE to review pages of rSO
2
data and locate the
desired time and value to set baselines to.
Once the time and data on the page being displayed has been located, perform the following
navigation bar options:
BASELINE MENU EVENT MARK ALARM AUDIO ON/OFF NEXT MENU
SET BASELINES SET CHANNEL MANUAL SET PREVIOUS MENU
CHANNEL 1 SET CHANNEL 2 SET CHANNEL 3 SET CHANNEL 4 SET
BASELINE MENU EVENT MARK ALARM AUDIO ON/OFF NEXT MENU
SET BASELINES SET CHANNEL MANUAL SET PREVIOUS MENU
NEXT PAGE PREVIOUS PAGE LAST PAGE SCROLL MENU
NEXT PAGE PREVIOUS PAGE LAST PAGE SCROLL MENU
NEXT PREVIOUS SELECT BASELINES PREVIOUS MENU
