Input Line Details
The input line signals have the following features for control or status indication.
• Feature Set:
Line Selector
(RW)
Line Format (RW)
Line Mode (RW)
Input Line Debouncing Period (RW)
Line Inverter (RW)
Line Status (RO)
Input Line Detection Level (RO).
• Connector: See HD15 Connector Details for connector pinout and electrical information. The
cable shell and shield should electrically connect the Linea Lite chassis to computer chassis for
maximum EMI protection.
• Input Line Debouncing Period: Each input incorporates a signal debounce circuit to eliminate
short noise transitions that could be wrongly interpreted as a valid pulse. The duration is user-
programmable from 0 µs to 255 µs.
• Line Input Signal Characteristics: See Input Signals Electrical Specifications
.
Output Line Details
The general purpose output line signals either dedicated or shared with inputs. For more
information, see HD15 Connector Details for connector pinout and
Output Signals Electrical
Specifications.
• Feature Set:
Line Inverter
(RW)
Output Line Source (RW)
Output Line Pulse Delay (RW)
Output Line Pulse Duration (RW)
Output Line Value (RW)
Output Line Software Command (RW)
Line Selector (RW)
Line Format (RW)
Line Mode (RW)
Line Status (RO).
• External Outputs: Can be used as a strobe signal to control lighting or to generate
programmable pulses when specific events are generated by the camera.
• Output on Events: Each output can be set independently to the available event modes defined
by the Output Line Source
feature. The output delay can be set from 0 to 16 seconds in
increments of 1 µs. The pulse duration can be set from 0 to 16 seconds in increments of 1 µs.
