Linea Lite GigE Series Camera Camera Performance and Features • 43
Example of Free Run Line Mode with Frame Trigger
An example setup of free run line acquisition with Frame Trigger and a configurable internal timer
is used as follows:
• Set AcquisitionLineRate
= 20000 Hz
• Set image Height = 100
• Select Trigger Selector = SingleFrameTrigger (Start)
• Set Trigger Mode = On
• Select Trigger Source = Timer1EndEvent
• Setup Timer1:
• Set Timer Start Source
= Timer1End
• Timer Duration = 5000
• Timer Mode set = Active
Then click the CamExpert Grab button.
Example of Line Trigger Mode
An example setup of a Line Trigger acquisition using internal timer with a configurable internal
timer is as follows:
• Set image Height
= 100
• Select Trigger Selector = SingleLineTrigger(Start)
• Set Trigger Mode = On
• Select Trigger Source = Timestamp Modulo Event
• Setup Timestamp Modulo Event:
• Use Timestamp Latch Cmd to start the timestamp using the camera’s internal clock
• timeStampModulo= 10000 (frame rate = 100 Hz)
Then click the CamExpert Grab button.
