1.5.2 Caution Notification
ACAUTION notificationsignifiesanessentialoperationormaintenanceprocedure,practice,orconditionwhich,if
notstrictlyobserved,couldresultindamagetoordestructionofequipmentorpotentialproblemsintheoutcome
oftheprocedurebeingperformed.ACautionnotificationisdisplayedintheformatshowninFigure1-4Caution
NotificationExample.
Figure 1-4 Caution Notification Example
• • • CAUTION • • •

1.5.3 Note
ANOTE providesadditionalinformationsuchasatip,comment,orotheruseful,butnotimperativeinformation.A
NoteisdisplayedintheformatshowninFigure1-5NoteExample.
Figure 1-5 Note Example
NOTE


1.6 Precautions
Considerationforpersonalsafetyandequipmentsafetyisveryimportant.Thischaptercontainsvarioussections
thatcoversafetyprecautionsandmethodsthatmustbefollowedwhenservicingthecompressor.Priortoservicing
thecompressor,carefullyreadthischaptertoensurefamiliarityofbothpersonalandequipmentsafety.
1.7 Refrigerant Type
Turbocor®compressorsaredesignedtobeappliedonlywithspecificrefrigerants.TheANSI/ASHRAE34Standard
(SafetyClassificationofRefrigerants)classificationshouldbetakenintoaccountwhendesigningandapplying
Turbocor®compressors.WealsostronglyrecommendfollowingthecurrentANSI/ASHRAEStandard15(Safety
StandardforRefrigerationSystems)orotherapplicablelocalstandardsforthemechanicalroomdesignand
applicationofallequipmentusingTurbocor®compressors.
Table 1-1 Refrigerant Type
Compressor Series Refrigerants ASHRAE/ANSI Standard 34 Classifications
TTS/TTH R134a,R513A A1
TGS/TGH R515B,R1234ze(E) A1,A2L

NOTE
Donotuserecycledrefrigerantasitmaycontainoil,whichcanaffectsystemreliability.Therefrigerantshouldbepureandstoredinvirgin
containers.

