5. PlacethelongM5x20fastenerandflatwasherinpositionnumberthree(3)showninFigure4-15
CapacitorCoverTorqueSequence.UsetheremainingM5x15fastenerstosecurethecover.Tightenall
fastenersaccordingtothesequenceinFigure4-15CapacitorCoverTorqueSequence.Torqueto13
in.lb.onthesecondpass.
6. Installthetopcovers.RefertoSection4.1CompressorCoversonpage52.
7. Returnthecompressortonormaloperation.
Figure 4-15 Capacitor Cover Torque Sequence
4.1.5 Compressor Cover Torque Specifications
Table 4-6 Compressor Cover Torque Specifications
Description Nm Ft.Lb. In.Lb.
CoverFastener,M5x15 1.5 - 13
CoverFastener,M5x20(#3onCapacitorCover) 1.5 - 13

M-SV-001-EN Rev. H-1/23/2023 Page 57 of 294
