Figure 6-3 Bearing Sensor Feedthrough Dielectric Grease Application
• • • CAUTION • • •
DonotapplyanydielectricgreasedirectlytobearingsensorfeedthroughDB9pins,onlyapplygreasearoundbearingsensorfeedthrough
connectorsafterthecablesareconnectedtopreventmoisturefromenteringthepinarea.

2. InstalltheMotor-CoolingValveSolenoidCoils.
3. ConnectthesolenoidactuatorandbearingsensorcablestotheBackplane.
4. InstalltheServiceSideCover.RefertoSection4.1.3.1ServiceSideCoverRemovalandInstallationon
page54.
6.2.1.3 Top Side
1. Removethetopcoversfromthecompressor.RefertoSection4.1CompressorCoversonpage52.
2. Dryoffanycondensatearoundthemotorwindingsensorterminals,highpowerfeedthroughsand
motorbusbars.
3. Usingasoft-bristlebrush,removeanydebrisordustfromthemotorwindingsensorterminals.
4. Sprayorapplydielectricgreaseonthemotorthermistorterminals.RefertoFigure6-4Motor
ComponentDielectricGreaseApplication.
5. Reinstalltopcovers.RefertoSection4.1CompressorCoversonpage52.
6. Returnthecompressortonormaloperation.
Figure 6-4 Motor Component Dielectric Grease Application
