Datalogic Gryphon I GBT4400 User Manual

Interface Selection Setup
Product Reference Guide 31
KEYBOARD FEATURES
Select USB Alternate Keyboard
USB Keyboard with alternate key encoding
AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70,
80, 90 & 95 w/Standard Key Encoding
Select KBD-AT
Set KEYBOARD
WEDGE
Interface
Features
starting on page
55
Select KBD-AT-NK
Keyboard Wedge for IBM AT PS2 with
standard key encoding but without
external keyboard
AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70,
80
, 90 & 95 w/Alternate Key
Select KBD-AT-ALT
Select KBD-AT-ALT-NK
Keyboard Wedge for IBM AT PS2 with
alternate key encoding but without
external keyboard
PC/XT w/Standard Key Encoding
Select KBD-XT
Select KBD-IBM-3153
Keyboard Wedge for IBM Terminal 3153
$P,HA2B,P(CR)
$P,HA29,P(CR)
$P,HA11,P(CR)
$P,HA26,P(CR)
$P,HA10,P(CR)
$P,HA28,P(CR)
$P,HA14,P(CR)

Datalogic Gryphon I GBT4400 Specifications

General

Wavelength	650 nm
Scanner type	2D
Yaw reading angle	-40 - 40 °
Tilt reading angle	0 - 360 °
Light levels (direct sunlight)	0 - 100000 lx
Input voltage	4.5 - 14.0 V
Battery capacity	2100 mAh
Number of reads per charge	60000
Bluetooth	Yes
Dimensions (WxDxH)	71 x 100 x 181 mm
Certification	China RoHS, EU RoHS, IEC 60825 Class 2
Product color	Black
LED indicators	Charging, Power
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Weight	245 g
