Datalogic Gryphon I GBT4400 User Manual

Setup Interface Selection
32 Gryphon™ I GD44XX / GBT4400/GM440X
KEYBOARD — cont. FEATURES
Keyboard Wedge for IBM Terminals
31xx, 32xx, 34xx, 37xx mak
e only key-
board
Select KBD-IBM-M
Set KEYBOARD
WEDGE
Interface
Features
starting on page 55
Select KBD-IBM-MB
Keyboard Wedge for IBM Terminals
31xx, 32xx, 34xx, 37xx make break key-
board
Keyboard Wedge for DIGITAL Termi-
nals VT2xx, VT3xx, VT4xx
Select KBD-DIG-VT
Select USB Keyboard
USB Keyboard with standard key encoding
USB Keyboard for Apple computers
Select USB-KBD-APPLE
WAND EMULATION FEATURES
Wand Emulation
( B T o n l y )
Select WAND
Set WAND
Interface
Features
starting on page 71
$P,HA15,P(CR)
$P,HA16,P(CR)
$P,HA1B,P(CR)
$P,HA35,P(CR)
$P,HA2C,P(CR)
$P,HA24,P(CR)

Datalogic Gryphon I GBT4400 Specifications

General

Wavelength	650 nm
Scanner type	2D
Yaw reading angle	-40 - 40 °
Tilt reading angle	0 - 360 °
Light levels (direct sunlight)	0 - 100000 lx
Input voltage	4.5 - 14.0 V
Battery capacity	2100 mAh
Number of reads per charge	60000
Bluetooth	Yes
Dimensions (WxDxH)	71 x 100 x 181 mm
Certification	China RoHS, EU RoHS, IEC 60825 Class 2
Product color	Black
LED indicators	Charging, Power
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Weight	245 g
