Engine running
The table illustrates the action of the fail classes. If, for instance, an alarm has been configured
with the ‘shutdown’ fail class, the following actions occur.
• The alarm horn relay will activate
• The alarm will be displayed in the alarm info screen
• The generator breaker will open instantly
• The gen-set is stopped instantly
• The gen-set cannot be started from the unit (see next table)
Engine stopped
Action
Fail class
Block engine start Block MB sequence Block GB sequence
1 Alarm X
2 Warning
3 Trip of GB X X
4 Trip and stop X X
5 Shutdown X X
6 Trip of MB X
Fail class configuration
The fail class can be selected for each alarm function either via the display or the PC software.
To change the fail class via the PC software, the alarm function to be configured must be
selected. Select the desired fail class in the fail class roll-down panel.
Action
Fail class
Alarm
horn
relay
Alarm
display
Deload Trip of
gen.
breaker
Trip of
mains
breaker
Cooling-
down
gen-set
Stop
gen-set
1 Alarm X X
2 Warning X X
3 Trip of GB X X X
4 Trip and stop X X (X) X X X
5 Shutdown X X X X
6 Trip of MB X X X
In addition to the actions defined by the fail classes, it is possible to activate
one or two relay outputs, if additional relays are available in the unit.
The fail class ‘trip and stop’ will only deload the gen-set before opening the
breaker, if option G5 (power management) is included.
