Dell Networking N4000 Series - LED Definitions

Hardware Overview 109
LED Definitions
This section describes the LEDs on the front and back panels of the switch.
Port LEDs
Each port on an N3000 series switch includes two LEDs. One LED is on the
left side of the port, and the second LED is on the right side of the port. This
section describes the LEDs on the switch ports.
100/1000/10000Base-T Port LEDs
Each 100/1000/10000Base-T port has two LEDs. Figure 3-20 illustrates the
100/1000/10000Base-T port LEDs.
Figure 3-14. 100/1000/10000Base-T Port LEDs
Link/SPD Activity
