Dell Networking N4000 Series User Manual

Configuring L2 Multicast Features 831
Copying MLD Snooping Settings to VLANs
To copy MLD snooping settings:
1
From the General MLD snooping page, click Show All .
The
MLD Snooping Table displays.
2 Select the Copy Parameters From checkbox.
3 Select a VLAN to use as the source of the desired parameters.
4 Select the Copy To checkbox for the VLANs that these parameters will be
copied to.
5 Click Apply .
The MLD snooping settings are modified, and the device is updated.
MLD Snooping Global Querier Configuration
Use the MLD Snooping Global Querier Configuration page to configure the
parameters for the MLD snooping querier.
To display the Global Querier Configuration page, click Switching
→
Multicast Support
→ MLD Snooping → Global Querier Configuration in
the navigation menu.
Figure 25-16. MLD Snooping Global Querier Configuration

Dell Networking N4000 Series Specifications

General

Layer	Layer 3
Switching Capacity	Up to 1.28 Tbps
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Series	N4000 Series
Stacking	Up to 12 units
Power Supply	Dual, hot-swappable
Management	Web, CLI, SNMP
Humidity	10% to 90% (non-condensing)
