Dell Networking N4000 Series User Manual

Configuring IPv6 Routing 1255
Configured IPv6 Routes
Use the Configured IPv6 Routes page to display selected IPv6 routes.
To display the page, click Routing
→ IPv6 → IPv6 Routes → Configured
IPv6 Routes in the navigation panel.
Figure 38-11. Configured IPv6 Routes
To remove a configured route, select the check box in the Delete column of
the route to remove, and click Apply.
NOTE: For a static reject route, the next hop interface value is Null0. Packets to
the network address specified in static reject routes are intentionally dropped.

Dell Networking N4000 Series Specifications

General

Layer	Layer 3
Switching Capacity	Up to 1.28 Tbps
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Series	N4000 Series
Stacking	Up to 12 units
Power Supply	Dual, hot-swappable
Management	Web, CLI, SNMP
Humidity	10% to 90% (non-condensing)
