Dell Networking N4000 Series

To Next Page

To Previous Page

114 Hardware Overview

Table 3-15. N3000 Series PoE Power Budget Limit

One PSU Support Two PSUs Support

Model

Name

System Power

Max. Dissipation

Max. PSU

Output Ability

POE+ Power

Turn-on Limitation

Max. PSUs

Output Ability

POE+ Power

Turn-on Limitation

N3024P 110W 715W Power budget is

550W:

The total POE

supplied power

must not exceed

550W.

715W Power budget is

1100W:

All PoE+ ports can

supply maximum

power.

N3048P 140W 1100W Power budget is

950W:

The total POE

supplied power

must not exceed

950W.

2200W Power budget is

1900W:

All PoE+ ports can

supply maximum

power.
