Dell Networking N4000 Series User Manual

Feature Limitations and Platform Constants 1427
Table A-2. Platform Constants
Feature N2000 Series N3000 Series N4000 Series
MAC addresses assigned per system 4 4 4
Reference CPU ARM Cortex
A9
ARM Cortex
A9
NetLogic
XLP308L
Reference CPU speed 1 GHz 1 GHz 1.2 GHz
Reference RAM 1 Gbyte 1 Gbyte 2 Gbyte
DDR3
Reference Flash 256 Mbyte 256 Mbyte 256 Mbyte
Maximum number of remote Telnet
connections
444
Maximum number of remote SSH
connections
555
Number of MAC addresses supported 8192 16384 131072
Maximum Agetime in seconds 1000000 1000000 1000000
Number of VLANs 4096 4096 4096
Maximum VLAN ID 4093 4093 4093
Number of 802.1p traffic classes 7 7 7
IEEE 802.1x
Number of .1x clients per stack
Number of .1x clients per port
2496
64
2496
64
2496
64
Number of LAGs (max. lags/ports/max
dynamic LAG ports per system
128/8/144 128/8/144 128/8/144
Maximum multiple spanning tree
instances
15 15 15
Number of MAC-based VLANs
supported
256 256 256
Number of network buffers 182 182 182
Number of records in log 400 400 400

Dell Networking N4000 Series Specifications

General

Layer	Layer 3
Switching Capacity	Up to 1.28 Tbps
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Series	N4000 Series
Stacking	Up to 12 units
Power Supply	Dual, hot-swappable
Management	Web, CLI, SNMP
Humidity	10% to 90% (non-condensing)
