Dell Networking N4000 Series User Manual

Configuring L2 Multicast Features 839
Figure 25-27. MVR - Add to Group
2 Select the interface to add to the MVR group.
3 Specify the MVR group IP multicast address.
4 Click Apply .
Removing an Interface from an MVR Group
To remove an interface from an MVR group:
1
From the MVR Interface page, click Remove .
Figure 25-28. MVR - Remove from Group
2 Select the interface to remove from an MVR group.
3 Specify the IP multicast address of the MVR group.
4 Click Apply .

Dell Networking N4000 Series Specifications

General

Layer	Layer 3
Switching Capacity	Up to 1.28 Tbps
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Series	N4000 Series
Stacking	Up to 12 units
Power Supply	Dual, hot-swappable
Management	Web, CLI, SNMP
Humidity	10% to 90% (non-condensing)
