958 Configuring Link Aggregation

VOIP No

iSCSI No

DOT1AD No

DOT3AH No

DCBX N/A

ETS N/A

FIP Snooping No

MVRP No

Management ACL No

UDLD N/A

Private VLAN No

LLPF No

Port Aggregator No

EAV No

MSRP No

MVR No

Class-Based VLAN No

DHCP Filtering No

EASY_ACL No

Media VLAN No

PBVLAN No

VLAN-Rate Limit No

Flow Control N/A

LLDP N/A

Jumbo Frames N/A

Table 28-2. MLAG State Synchronization Per Feature (Continued)

Components MLAG State Synchronization Support
