FCoE-
generated
ACLs
These take precedence over user-configured ACLs. A user-configured ACL entry
cannot deny FCoE and FIP snooping frames.
The following illustration shows a switch used as a FIP snooping bridge in a converged Ethernet network.
The top-of-rack (ToR) switch operates as an FCF for FCoE traffic. Converged LAN and SAN traffic is
transmitted between the ToR switch and an S4820T switch. The switch operates as a lossless FIP
snooping bridge to transparently forward FCoE frames between the ENode servers and the FCF switch.
Figure 39. FIP Snooping on an S4820T Switch
The following sections describe how to configure the FIP snooping feature on a switch:
FCoE Transit
363
