Figure 46. Membership Queries: Leaving and Staying

Configure IGMP

Configuring IGMP is a two-step process.

1. Enable multicast routing using the ip multicast-routing command.

2. Enable a multicast routing protocol.

Related Configuration Tasks

• Viewing IGMP Enabled Interfaces

• Selecting an IGMP Version

• Viewing IGMP Groups

• Adjusting Timers

• Preventing a Host from Joining a Group

• Enabling IGMP Immediate-Leave

• IGMP Snooping
