Examples of Setting and Viewing a Dead Interval
In the following example, the dead interval is set at 4x the hello interval (shown in bold).
Dell(conf)#int tengigabitethernet 2/2
Dell(conf-if-te-2/2)#ip ospf hello-interval 20
Dell
(conf-if-te-2/2)#ip ospf dead-interval 80
Dell(conf-if-te-2/2)#
In the following example, the dead interval is set at 4x the hello interval (shown in bold).
Dell (conf-if-te-2/2)#ip ospf dead-interval 20
Dell (conf-if-te-2/2)#do show ip os int tengigabitethernet 1/3
TenGigabitEthernet 2/2 is up, line protocol is up
Internet Address 20.0.0.1/24, Area 0
Process ID 10, Router ID 1.1.1.2, Network Type BROADCAST, Cost: 1
Transmit Delay is 1 sec, State DR, Priority 1
Designated Router (ID) 1.1.1.2, Interface address 30.0.0.1
Backup Designated Router (ID) 1.1.1.1, Interface address 30.0.0.2
Timer intervals configured, Hello 20, Dead 80, Wait 20, Retransmit 5
Hello due in 00:00:04
Neighbor Count is 1, Adjacent neighbor count is 1
Adjacent with neighbor 1.1.1.1 (Backup Designated Router)
Dell (conf-if-te-2/2)#
Configuration Information
The interfaces must be in Layer-3 mode (assigned an IP address) and enabled so that they can send and
receive traffic. The OSPF process must know about these interfaces.
To make the OSPF process aware of these interfaces, they must be assigned to OSPF areas.
You must configure OSPF GLOBALLY on the system in CONFIGURATION mode.
NOTE: Loop back routes are not installed in the Route Table Manager (RTM) as non-active routes.
OSPF features and functions are assigned to each router using the CONFIG-INTERFACE commands for
each interface.
NOTE: By default, OSPF is disabled.
Configuration Task List for OSPFv2 (OSPF for IPv4)
The following configuration tasks include two mandatory tasks and several optional tasks:
• Enabling OSPFv2 (mandatory)
• Assigning a Router ID
• Assigning an OSPFv2 Area (mandatory)
• Enable OSPFv2 on Interfaces
• Configuring Stub Areas
• Enabling Passive Interfaces
• Enabling Fast-Convergence
• Changing OSPFv2 Parameters on Interfaces
Open Shortest Path First (OSPFv2 and OSPFv3)
695
