MIB Support to Display the Available Memory Size on
Flash
Dell Networking provides more MIB objects to display the available memory size on flash memory. The
following table lists the MIB object that contains the available memory size on flash memory.
Table 76. MIB Objects for Displaying the Available Memory Size on Flash via SNMP
MIB Object OID Description
chStackUnitFlashUsageUtil 1.3.6.1.4.1.6027.3.10.1.2.9.1.6 Contains flash memory usage in
percentage.
The chStackUnitUtilTable MIB table contains the chStackUnitFlashUsageUtil MIB object which contains
the flash memory usage percent. The chStackUnitUtilTable is located in f10SSerChassisMib MIB.
Viewing the Available Flash Memory Size
• To view the available flash memory using SNMP, use the following command.
snmpget -v2c -c public 192.168.60.120 .1.3.6.1.4.1.6027.3.10.1.2.9.1.6.1
enterprises.6027.3.10.1.2.9.1.5.1 = Gauge32: 24
The output above displays that 24% of the flash memory is used.
MIB Support to Display the Software Core Files Generated
by the System
Dell Networking provides MIB objects to display the software core files generated by the system. The
chSysSwCoresTable contains the list of software core files generated by the system. The following table
lists the related MIB objects.
Table 77. MIB Objects for Displaying the Software Core Files Generated by the System
MIB Object OID Description
chSysSwCoresTable 1.3.6.1.4.1.6027.3.10.1.2.10 This is the table that contains the
list of software core files
generated by the system.
chSysCoresEntry 1.3.6.1.4.1.6027.3.10.1.2.10.1 Entry number.
chSysCoresInstance 1.3.6.1.4.1.6027.3.10.1.2.10.1.1 Stores the indexed information
about the available software core
files.
chSysCoresFileName 1.3.6.1.4.1.6027.3.10.1.2.10.1.2 Contains the core file names and
the file paths.
Simple Network Management Protocol (SNMP)
943
