Delta DPS-400K - Standard Compliance

1-6
Ultron DPS Series
No. Symbol Description
28
Input Switch/ Bypass Switch/ Manual Bypass Switch/ Output
Switch is in the OFF position.
29
Static Switch is in the OFF position.
30
Input Switch/ Bypass Switch/ Manual Bypass Switch/ Output
Switch/ Static Switch is in the ON position.
31
Parallel cable is abnormal.
32
Parallel cable connected.
33
Bypass frequency unstable.
34
Battery test cannot be executed.
35
Cursor
36
When the symbol changes to the symbol , it means
that you can change your selected item’s setting.
37
!
Flashes when an alarm/ event occurs.
38
Goes back to previous screen or cancels current selection.
39
Moves up.
40
Moves down.
41
Moves left.
42
Moves right.
43
Increases number.
44
Decreases number.
45
&RQ¿UPVVHOHFWLRQ
1.6 Standard Compliance
y
EN 62040-1
y
EN 62040-2 C3
y
IEC 61000-4-2 Level 4
y
IEC 61000-4-3 Level 3
y
IEC 61000-4-4 Level 4
y
IEC 61000-4-5 Level 4
y
IEC 61000-4-6
