No. Item Quantity
6
Key
1 pc (two copies placed inside
the UPS cabinet)
7
REPO Dry Contact Terminal Block 1 set (2-Pin)
8
Input Dry Contact Terminal Block 1 set (4-Pin)
9
Rodent-proof Shield A
Rodent-proof Shield B
Rodent-proof Shield C
Rodent-proof Shield D
2 pcs
2 pcs
1 pc
1 pc
10
USB Cable 1 pc
11
Output Dry Contact Terminal Block 1 set (12-Pin)
4. If there is any damage or anything missing, please immediately contact the dealer
from whom you purchased the unit.
5. If the UPS needs to be returned, carefully repack the UPS and all of the accessories
using the original packing material that came with the unit.
6.5 Installation
1
Before installation, please refer to 5.1 Before Installation and 5.2 Installation
Environment.
2
The Top Cable Entry Cabinet has been joined together with the UPS before the UPS is
VKLSSHGRXWRIWKHIDFWRU\%HIRUH¿[LQJWKH836LQDGHVLJQDWHGDUHDSOHDVHGRXEOH
FKHFNZKHWKHUWKHDUHD¶VÀRRUZHLJKWORDGLQJLVVXI¿FLHQWWREHDUWKH836WRDYRLG
accidents. Please refer to Table 6-1.
Table 6-1: UPS (with Top Cable Entry Cabinet) Floor Weight Loading Table
DPS series UPS (with Top Cable Entry Cabinet)
Rating (kVA) 300 400 500
Weight (Kg) 1181 1181 1271
Weight Loading (kg/m²) 765 765 925
3
There are eight balance supports locating at the front bottom and the rear bottom
RIWKH8363OHDVHXVHDPPEXVKLQJWRRODQGHLJKWH[SDQVLRQVFUHZVWR¿[WKH
UPS’s eight balance supports on the ground; please refer to Figure 6-2: Mounting
Hole Diagram and Figure 6-3: Balance Support Installation. Please note that
service personnel should provide the expansion screws.
