6-2
Ultron DPS Series
If the UPS that you purchased includes the Top Cable Entry Cabinet, the Top Cable Entry Cabinet
has been joined together with the UPS before the UPS is shipped out of the factory. For relevant
information, please refer to the following.
6.1 Exterior & Dimensions
(Figure 6-1: Exterior & Dimensions (with Top Cable Entry Cabinet))
UPS
1950
mm
865
mm
1600
mm
184
mm
816
mm
Top Cable
Entry Cabinet
6.2 Functions
The Top Cable Entry Cabinet is exclusively designed for the Delta Ultron 300kVA, 400kVA
or 500kVA UPS (hereafter referred to as UPS). It facilitates a site that needs the application
of top cable entry when you use the UPS.
6.3 Important Safety Instructions
For safety instructions and package inspection, please refer to 1. Important Safety
Instructions and 6.4 Package Inspection.
