5-7
5
Installation and Wiring
(Figure 5-6: Install the Rodent Shields at each Lateral Side of the UPS)
(Side View)
M4
Screw
Rodent Shield C
(M4 Screw x 4)
5
After you complete the procedures above, the front view of the UPS is as follows.
(Figure 5-7: Front View after Rodent Shield Installation)
