Cleaning the Machine 9-11
4 Close the tray 2.
5 Open the machine’s front cover.
6 Remove the waste toner bottle
and the toner cartridge and
imaging unit for the color of
laser lens to be cleaned.
d
For details on removing the
toner cartridge, imaging unit
or waste toner bottle, refer to
“Replacing a Toner Car-
tridge” on page 8-5 or
“Replacing an Imaging Unit”
on page 8-10.
d
Do not tilt removed toner
cartridge, otherwise toner
may spill.
d
Do not tilt removed waste toner box, otherwise waste toner may spill.
7 Attach the cover to the removed
imaging unit.
To Next Page
