Dual In-Line Memory Module (DIMM)11-6
5 Insert the DIMM at an angle
(about 45°) into the connector,
making sure that the notch on
the unit aligns with the tab on
connector, and then press down
carefully until it clicks into place.
d
Be sure to handle the
DIMM by the edges only.
d
You will hear a click when
the DIMM is properly
placed.
6 Attach the cover, and then tighten the screw.
7 Close the rear cover.
8 Reconnect all interface cables.
9 Reconnect the power cord, and turn on the machine.
10 Declare the additional memory in the Windows printer driver ([Properties]/
[Configure] tab).
11 Print a configuration page ([REPORT/STATUS]/[REPORT]/[CONFIGURA-
TION PAGE]) and verify that the total amount of the RAM installed in this
machine is listed.
