Dickey-John Flex4 Pro - Import;Export Data Files; Passcode Enabled; Export Configuration Files

DATA
IMPORT
DONE
BACK
DATA
IMPORT
DONE
BACK
DATA
IMPORT
DONE
YOUMUSTREBOOTTHETERMINALTOSAVE
ALLIMPORTEDDATA
REBOOT
TERMINAL
OPERATOR’S MANUAL
IMPORT/EXPORT DATA FILES
Two separate functions can be performed with the Import/Export button.
• Import/export of system configuration settings to a USB memory
device to import to other tablets
• Export of logged data files for reporting purposes
PASSCODE ENABLED
If a driver passcode is enabled at the Configuration Setup screen, this
passcode is required before importing or exporting files can occur. The code
can be entered on the Passcode screen or by using an attached keyboard.
The Passcode screen appears after pressing the Import/Export button.
Enter the passcode and press the Enter button to proceed.
Figure 103
Passcode Screen
NOTE: USB memory device must be
inserted into the USB port
before the Import/Export
button appears.
EXPORT CONFIGURATION FILES
To export Configuration Files:
1. Insert USB memory device into USB port.
2. At the Operate screen, an Import/Export button appears after the
USB memory device is inserted.
3. Press the Import/Export button.
4. At the Import Export screen, select Config USB Export button. The
Export to USB confirmation screen displays the file name that contains
the configuration files.
5. Press the Export Now button.
6. A Data Export Done screen indicates file transfer is complete.
Flex4 Pro
TM
Control System
6010541 Rev A
IMPORT/EXPORT DATA FILES / 121
ENTERCONFIGURATIONPASSCODE
1 
7 
2 
8 
3 
9 
4 
0 
5 
6 
BACK
ENTER
