OPERATOR’S MANUAL
FLEX4
PRO
TM
PROGRAMMING
A keyboard is required to program and calibrate the system. The keyboard
is removed after programming is complete. System will not allow entry of
setup menus, calibration, or configuration without a keyboard attached.
IMPORTANT: After plugging in the keyboard, the Flex4 Pro
TM
tablet
screen must be touched first before the keyboard
becomes active and usable.
Function keys (F1 through F12) located at the top of the keyboard are used
to display 12 menu screens that define desired system settings.
Configuration parameters can be changed on menu screens by using the
up and down arrow keys on the keyboard or by selecting the configuration
parameter by screen touch.
Access to menus using keyboard function keys include:
•
F1 Operate screen
•
F2 Granular Channel Setup
•
F3 Liquid Channel Setup
•
F4 Auxiliary S Granular/Liquid/Spinner Channel Setup
•
F5 Auxiliary Granular/Liquid Channel Setup
•
F6 Calibration
•
F7 Diagnostics
•
F8 Ground Speed Setup
•
F9 Accessory Sensor Setup
•
F10 System Setup
•
F11 Output Module Setup
•
F12 Data Logging
PASSCODE RESTRICTIONS
Two types of passcodes are optional and can be enabled to require a driver/
supervisor to:
•
Login with a passcode before driver operation is allowed
•
Login to gain access and change configuration setup values with a
keyboard
The system passcode settings are shipped as disabled. Passcodes can be
enabled at the (F10) System screen (Driver Login Setup).
Once passcode settings are enabled, the codes are required before a driver
begins operation or configuration setup screens are accessed. Passcodes
can be any combination of numbers up to 10 digits.
Flex4 Pro
TM
Control System
6010541 Rev A
FLEX4 PROTM PROGRAMMING / 47
