OPERATOR’S MANUAL
NOTE: After plugging in the keyboard,
the Flex4 Pro
TM
tablet screen
must be touched first before the
keyboard becomes active and
usable.
DIAGNOSTICS
Diagnostic screens (F7) can be used to check system performance by
displaying sensor input readings that connect to the PCECU, control
module, and output module that could indicate potential issues.
Three Diagnostic screens are available and selected based on where the
sensor is connected:
•
PCECU (joystick inputs)
•
Control module (control channels, spinner, auxiliary sensors)
•
Output module (added accessories)
PERFORM A DIAGNOSTICS CHECK (F7)
To perform a diagnostics check, vehicle ground speed must be zero and
manual ground speed must be enabled at the appropriate ground speed
setting. Actual readings will display on the Diagnostics screen at the defined
rate and the manual ground speed entered when the switch module Auto
On button is enabled.
Enable Manual Ground Speed:
1.
Enable manual ground speed with the vehicle stopped and the switch
module Auto On/Off button in Off mode.
2.
At the Operate screen, press the Material Select button to display the
Material Selection screen.
3.
Press the Manual Speed button to select Enable Manual Speed.
4.
Press the Select button to enter the appropriate ground speed to
perform test.
5.
Press the Back button to return to the Operate screen. Verify that the
manual speed is active on the screen.
6.
Connect the keyboard to access the Diagnostics screen and press the
F7 button on the keyboard to display the Diagnostics screen.
Flex4 Pro
TM
Control System
6010541 Rev A
DIAGNOSTICS / 129
